Conveyor HDPE Idler Roller Spare Parts

High-density polyethylene (HDPE) or polyethylene high-density (PEHD) is a polyethylene thermoplastic made from petroleum. It is sometimes called "alkathene" or "polythene" when used for pipes. The features of HDPE idlers are anti-corroding, low rotation resistance, good balance, light weight and power saving and anti-static formulation. And the Roller be application to coal mining, cement, concrete, limestone and quarry also specialize to fertilizer, salt, sugar, pulp paper, acid and alkaline. XKTE specializes in producing ball beairng for Conveyor Idler Roller and also supply spare parts throughout the world.

Item	Description	Q'ty
1	Shell	1
2	Bearing Housing	2
3	Shaft	1
4	Inner Snap Ring	2
5	Bearing	2
6	Female Labyrinth Seal	2
7	Male Labyrinth Seal	2
8	Outer Labyrinth Seal	2
9	Outer Snap Ring	2
10	Cover	2

Features
HDPE pipe with Reinforced Skeleton
Light Weight for Power Saving and Worker Safety
Smooth, Noiseless operation
Anti-Static Formulation
Suitable for Corrosion Environment

Bearing.Large clearance C3/C4 serials deep groove ball bearings, reinforced cage with big rivet, thick inner ring and outer ring. usually use double sealed structure to improve the water and dust proof ability.

Unique Design Seize-Resistant Deep Groove Ball Bearings: 6200 series-6300 series

1. KA/TN/TN9 nylon retainer Type

2. Open Type

3. Sealed Type

4. CSK series One Way Clutch Bearing

Other Main Products for idler:

6200/6300 series Deep Groove Ball Bearing

6200/6300 series ball bearings are well suited for low to heavy radial loads and can be configured for various application speeds and running precision requirements. Reinforced iron Retainer, Super-finished deep groove, smooth race, thicker inner and outer ring.

6200/6300 Series Deep Groove Ball Bearing
Model	Bore Size(mm)	Outer Diameter(mm)	High(mm)	Weight(kg)	ball no.	Cr(kN)	Cor(kN)
6204	20	47	14	0.106	8	12.8	6.65
6205	25	52	15	0.128	9	14	7.85
6305	25	62	17	0.232	7	20.6	11.3
6306	30	72	19	0.346	8	26.7	15
6307	35	80	21	0.457	8	33.4	19.3
6308	40	90	23	0.639	8	40.8	24
6309	45	100	25	0.837	8	52.8	31.8
6310	50	110	27	1.082	8	61.8	38
Material Chrome Steel GCr15

Conveyor Idler Roller Size:

Standard Diameter		Standard Inner Diameter(mm)	Length scope(mm)	Bearngs Type
mm	Inch			(Min-Max)
89	3 1/3	60/50	170-3400	6204
102	4	76	170-3400	6204 6205
108	4 1/4	89/76/60	170-3400	6204 6205
114	4 1/2	89/76	170-3400	6204 6205
127	5	89	170-3400	6204 6205
133	5 1/4	89/70/63.5	170-3400	6204 6205
140	4 1/2	89	170-3400	6204 6205
152	6	108/76	170-3400	6204 6205 6206 6305 6306
159	6 1/4	108	170-3400	6204 6205 6206 6305 6306
194	7 5/8	159/133	170-3400	6205 6206 6305 6306 6307 6308

Features:
Support the return belt
Excellent roundness, good dynamic balancing
Smooth operation, easy replacement
Long service life, maintenance-free

Special: XKTE - Ball Bearings and Rolling Bearings in Conveyor Technology

XKTE is the specialist in rolling bearing technology for the mechanical application of continuous conveyors.

Whether bulk or general cargo conveyor, we have the right solutions for your requirements. Application-optimized rolling bearings from XKTE master all challenges: Heavily different temperatures, moisture, dust, dirt, as well as noise and vibration reduction.

About US:

Shandong Xinkaite Bearing Co., Ltd. is a professional belt Conveyor Roller Bearing manufacturer enterprise, specialized in manufacturing bearings for the bulk material handling industry and supply all kinds of Conveyor Idler Components. our bearings are being used in multiple applications including: mining machinery, carrying idlers and reverse rollers as well as drum pulley. Our factory is located in Yandian of Liaocheng in mainland China, covered an area of 18,000 square meters, registered trademarks "XKTE".

And there are many long-term fixed partners of ours within the areas centered by Conveyor Roller bearing industry. With our company`s gradually growing, from the rough to the bearing, we set up a one-stop production line, with 50000 pieces produced every day on our automated production lines. all products are manufactured according to GB standards or in compliance with your specific requirements.

Our Service:

1. Volume production and large Inventories, stable quality

2. OEM is supported

3. Small order accept

4. Various Brands

5. Wide Array of Applications

6. Fast delivery

7. Our company insists on the "quality first, credit first" business ideas and our product specification is well-founded. We have a good reputation in the international market by our perfect service and sufficient supply.

Packing

Looking for ideal HDPE Idler Roller Parts Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the HDPE Idler Roller Spare Parts are quality guaranteed. We are China Origin Factory of HDPE Roller Parts. If you have any question, please feel free to contact us.

Product Categories : Conveyor Components > Conveyor Idler Components
